Product Features
■ Support GSM/SMS/EGPRS/ LTE CAT M1/ LTE CAT NB2 (iOT network)
■ GNSS: GPS/Beidou/Glonass/Galileo/Qzss etc
■ GNSS/Wi-Fi/LBS triple positioning way, Real time tracking /upload data regularly
■ Built-in temperature sensor, support temperature alarm（Customization)
■ Built-in light sensor, detecting opening door/box behavior. Support Light alarm
■ As a host which connect 24 beacons at most, it can gather temperature & humidity data from
Beacon model(like SYL01) by BLE, then upload all data to server regularly.
■ 5500mAh rechargeable lithium Battery
■ Low power alarm, Vibration alarm, GEO-fence alarm
■ Support Firmware upgrade by OTA
■ Third party platform integration
Specifications
| Item | Parameter |
| Work Current | LTE data (400mA); GPRS data (500mA) Idle (3mA); 30uA (power off) |
| GNSS Accuracy | <2M @ Open Sky |
| GNSS Band | 1575MHz |
| EGPRS Band | 850/900/1800/1900MHz |
| LTE CAT M1 Band | B1/B2/B3/B4/B5/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85 |
| LTE CAT NB2 Band | B1/B2/B3/B4/B5/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B71/B85 |
| BLE Max Connections | 24 Beacons |
| Hot/warm/cold Start | <3s，<26s，<35s |
| Battery | 5500mAh; 3.3~4.2V; Charge 5V@1A |
| Dimensions (mm) | 120(L) X 69(W) X 19.5(H) |
| Temperature/Humidity | -20℃~60℃ / 20%～90%RH |
| Net Weight | 165g |
