Product Features
 |
OBD Plug and Play Interface OBD Standard port, No need wiring or installing requirement |
 |
Speeding Detection When the GPS speed is greater than the setting speed, an speeding alarm will be reported |
 |
Low Voltage Detection When the vehicle voltage drops below 5V, the power off alarm will be reported. |
 |
4G The terminal supports 4G full network services |
 |
ACC Detection Ignition Detection |
 |
AGNSS Assisted Positioning Support AGNSS (assisted positioning) function, speed up GPS positioning. |
Specifications
| No. | Items | Specifications |
|---|---|---|
| 1 | Working Voltage | DC9-36V |
| 2 | Working Current | 45mA@12V (Static Current 9mA) |
| 3 | Size | L61mm × W52mm × H26mm |
| 4 | Weight | About 63g |
| 5 | Positioning Method | GPS + BDS + LBS |
| 6 | Positioning Accuracy | <10m CEP |
| 7 | Network | 4G |
| 8 | Communication Method | TCP |
| 9 | Working Temperature Range | -25℃ ~ +75℃ |
| 10 | Storage Temperature Range | -40℃ ~ +85℃ |
| 11 | Back-up Battery | 30 minutes (50mA/h) |
Specifications are for reference only; please refer to the product manual for accurate data.
