Product Features
 |
Fuel Cut Off Remotely Cut off fuel supply by command via the platform or SMS. |
 |
Speeding Detection When the GPS speed is greater than the setting speed, an speeding alarm will be reported |
 |
Low Voltage Detection When the vehicle voltage drops below 5V, the power off alarm will be reported. |
 |
4G The terminal supports 4G full network services |
 |
ACC Detection Ignition Detection |
 |
AGNSS Assisted Positioning Support AGNSS (assisted positioning) function, speed up GPS positioning. |
Specifications
| No. | Items | Specifications |
|---|---|---|
| 1 | Input Voltage | 9-90V DC with overvoltage protection |
| 2 | Working Current | 12V@4.5mA (Online sleep) 12V@30mA (Normal) |
| 3 | Dimensions | L81*W42*H13.5 mm |
| 4 | Weight | 70g |
| 5 | Positioning Way | GPS+BDS+LBS |
| 6 | Positioning Accuracy | <2.5m CEP |
| 7 | Communication Network | 4G |
| 8 | Communication Method | TCP |
| 9 | Working Temperature | -20℃~+75℃ |
| 10 | Storage Temperature | -40℃~+85℃ |
| 11 | Battery | 55mAh |
*Specifications are for reference only, please refer to the product manual for accurate data.
