Product Features
 |
Fuel Cut Off Remotely Cut off fuel supply by command via the platform or SMS. |
 |
Overspeed Detection When the GPS speed is greater than the setting speed, an overspeed alarm will be reported |
 |
Low Voltage Detection When the vehicle voltage drops below 5V, the power off alarm will be reported. |
 |
SOS Contact dispatch or emergency support by press panic button. |
 |
ACC Detection Ignition Detection |
 |
AGNSS Assisted Positioning Support AGNSS (assisted positioning) function, speed up GPS positioning. |
 |
Mic Two way communication |
Core Functions
| Function | Function Details | Function Description |
|---|---|---|
| Positioning | Real-time tracking | Positioning information such as longitude and latitude will be uploaded to the platform according to the set interval. |
| Vehicle Status Detection | Power Off Alarm | The power off alarm will be reported when the vehicle voltage drops below 5V. |
| Low Voltage Alarm | The low voltage alarm will be reported when the vehicle voltage is below 9V. | |
| Overspeed Alarm | The platform sets a maximum speed limit value. When the GPS speed exceeds the set value, an overspeed alarm will be reported. | |
| Other Functions | Blind Spot Data Upload | Records up to 500 pieces of blind spot data in the device when there is no signal, and uploads the data when the device reconnects to the network. |
| Corner Compensation | When the device’s angle changes more than a certain threshold, it uploads a location packet to the platform. | |
| Remote upgrade | Upgrade the device via OTA. |
Specifications
| No. | Items | Specifications |
|---|---|---|
| 1 | Input Voltage | 9-90V DC |
| 2 | Working Current | 12V@5mA (Online sleep) 12V@30mA (Normal) |
| 3 | Dimensions | L86*W43*H15 mm |
| 4 | Weight | 70g |
| 5 | Positioning Way | GPS+BDS+LBS |
| 6 | Positioning Accuracy | <10m CEP |
| 7 | Communication Network | 2G+4G |
| 8 | Communication Method | TCP |
| 9 | Working Temperature | -20℃~+75℃ |
| 10 | Storage Temperature | -40℃~+85℃ |
| 11 | Battery | 180mAh |
*Specifications are for reference only, please refer to the product manual for accurate data.
