Overview
The SYL01 Beacon is an advanced real-time temperature tracking device utilizing the latest Bluetooth 5.0 beacon technology. This powerful device serves as both a temperature data logger and a real-time positioning tracker. It is ideally suited for industries where precise temperature control is critical, providing robust features and functionality for real-time temperature monitoring and location tracking.
When combined with relevant software or apps, the SYL01 forms a comprehensive real-time temperature monitoring solution. It allows for online analysis, data storage, and temperature data caching, ensuring that your products remain within the desired temperature range.
Key Features of Beacon BLE SYL01
- Compact, Lightweight Design: The SYL01 is small and lightweight, which prevents potential issues with device management due to bulk. Its wireless setup also eliminates the complexity of wired installations, making it easy to install anywhere. It is battery-powered, requiring no external power source, saving labor costs.
- Low Power Consumption: One of the most attractive features of the SYL01is its ultra-low power consumption. The device boasts a standby life of 3 to 5 years without needing to recharge, making it highly reliable for long-term deployments.
Key Functions
- High-Precision Temperature Sensor: The SYL01 is equipped with a highly accurate temperature sensor capable of monitoring a wide temperature range from -40°C to 125°C, ensuring precise data collection.
- IP67 Waterproof and Dustproof Rating: The device is designed to withstand harsh environments, offering IP67-rated protection from water and dust.
- Data Caching: The SYL01 provides up to 4 days of local data caching in default mode, ensuring that no data is lost in case of transmission interruptions.
- Compact and Easy to Use: Its small form factor and easy installation make the SYL01 ideal for a variety of environments and applications.
- Long Battery Life: With a battery life of 3 to 5 years, the device requires no frequent charging or maintenance, significantly reducing operational costs.
- Real-Time Data Transmission: The SYL01 supports real-time temperature data collection, storage, and uploading, providing instant insights and alerts as needed.
- Customizable Features: The device supports custom feature enhancements, allowing clients to request tailored modifications to meet their specific business needs.
The SYL01 Beacon is an ideal solution for industries requiring accurate, real-time temperature monitoring. Its combination of long battery life, wireless setup, and high precision make it an efficient, cost-effective choice for cold chain logistics, pharmaceuticals, and other temperature-sensitive sectors.
Specifications
| Parameter | Details |
|---|---|
| Waterproof Rating | IP67 |
| Case Material | PC (Polycarbonate) |
| Case Color | Blue |
| Voltage | 3.0V |
| Standby Current | 5uA – 16uA |
| Peak Current | 10mA – 45mA |
| Dimensions | 66.5 (L) x 56 (W) x 6.7 (H) mm |
| Battery Type | Li-MnO2 (Lithium Manganese Dioxide) |
| Battery Capacity | 1350mAh |
| Wireless Technology | BLE Bluetooth Low Energy 5.0, nRF52840 chipset |
| Transmission Range | Up to 500 meters in open space |
| Broadcast Power | 8dB |
| Average Current | 25uA |
| Accessories | 3M Adhesive |
| Sampling Period | Configurable based on customer requirements |
| Temperature Sensor Accuracy | ±0.5°C (0°C to 65°C), ±1.0°C (-40°C to 125°C) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -30°C to +80°C |
| LED/Button | Blue LED/Power ON; Red LED/Power OFF |
