| OS |
Linux |
| Language |
Chinese/English/Others (can be customized) |
| Video Compression |
H.265. H.264 |
| OSD |
Overlays information such as date time and vehicle ID |
| GUI |
Interface |
Support external LED screen, configuration via remote control or USB Mouse |
| Video and Recording |
Video Input |
4CH in 1CH, and support 3CH AHD 1080P /720P |
| Video Output |
1CH AV Output |
| Preview |
1CH, 2CH,4CH optional |
| Resolution |
1080P/720P/D1/HD1/CIF； support 4CH full 1080P |
| Image Quality |
0-7 levels, 0 is the highest level, 7 is the lowest level. |
| Frame |
PAL: 100f/s , CCIR625 line,50field;
NTSC: 120f/s, CCIR525 line,60field; |
| Recording Mode |
ACC Power on.Timed recording, alarm recording and etc |
| Audio |
Input |
2CH ,(1CH built-in , 1CH External) |
| Output |
1CH |
| Compression |
G.726, G711a optional |
| Alarm |
5ch input, 1CH output |
| Communication Interface |
2CH RS232, 1CH RS485 |
| Wireless transfer |
Support Built-in 3G/4G network, WCDMA,CDMA2000, TTD-LTE, FDD-LTE compatible with GPRS,EDGE; Optional with WIFI modular (AP, STATION MODE) |
| Video Storage |
Storage |
Max support 2X256GB SD Card |
| Upgrade |
Support USB flash disk updating,TF card upgrade ,remote upgrade automatically |
| System |
Special vehicle File System |
| Playback
Video playback |
Search |
Search video by Record Time/Record Type etc |
| Playback |
Support max4ch playback. forward or backward play |
| Support x 2,x4,x8,x16. forward or backward play |
| Security Management |
User/Admin 2Passwords ,screen lock |
| TTS |
TTS Alert broadcasting |
|
Power&
Consumption |
Power management |
Adaptive wide power input, with overload, under-voltage, short circuit, reverseconnection and other protection functions; Support the timing switch machine, delay shutdown function. |
| Voltage input |
DC:+10V – +36V |
|
12V @1.2A 1 channels,with IR
12V @0.9A 1channels,with IR |
| Power shut down protection |
UPS Technology,All video information can be saved automatically when the power is cut off, and make sure that all the files can not be damaged. |
| Consumption |
Working mode ＜14W, Standby mode＜0.5W |
| Working Environment |
Temperature |
-40℃ – +70℃ |
| Humidity |
20% – 80% |
| Other |
Size |
135mm*94mm |
