| System |
Operating System |
Embedded Linux Operating System |
| Operating Language |
Chinese/English |
| Operation Interface |
Configured via Operation and Maintenance Tool |
| Audio & Video |
Compression Standard |
H.265/H.264 |
| Image Resolution |
1080P/720P/960H/D1/CIF |
| Recording Quality |
1 to 6 Levels Available |
| Audio Compression |
G.711A, G.711U, G.726 |
| Recording & Playback |
Recording Method |
Automatic, Alarm |
| Audio Bitrate |
8Kb/s |
| Playback Query |
Search by Channel, Recording Type |
| Software Upgrade |
Upgrade Mode |
Automatic, Remote |
| Upgrade Method |
USB Drive, TF Card, Wireless Network |
| Interface |
1 ACC Signal Input |
| Interfaces |
One-Key Alarm |
1 Channel |
| Audio Input |
Built-in MIC |
| Audio Output |
Built-in 2W Speaker |
| TF Card |
1 TF Card Slot |
| Extended Functions |
GNSS |
Built-in Ceramic Antenna, GPS+BD+GLONASS |
| Wireless |
Supports 4G Network |
| WIFI |
2.4GHz Frequency |
| Others |
Power Input |
DC: 8V~36V |
| Typical Power Consumption |
Less than 5W |
| Operating Temperature |
-20°C to 70°C |
| Storage Capacity |
1080P 600MB/hour/channel H.265, 1080P 1200MB/hour/channel H.264 |
| Dimensions |
125.6*86.6*46.9mm |
