Specifications
| ITEM | Technical Specifications |
|---|---|
| CPU | Dual-Core processor @ 1.5GHz, total coding resources 1080p*100fps NPU @ 1.0 TOPS neural network acceleration engine |
| Memory | 2GB DDR3 |
| Video Input | Active Pixels: 1920×1080, 1080×720; H.264 & H.265 format 1-ch Built-in CMOS camera, low illumination 0.01 LUX 3-ch External camera, AHD 720P @ 25fps |
| Video Output | Not supported; mobile app preview and setting available |
| Audio Input / Output | Built-in MIC and speaker, G.711a format |
| Video Recording Resolution | 1080P/720P/D1 @ 25fps; simultaneous recording of sound and video |
| G-Sensor | Built-in 3-axis acceleration sensor |
| External Interface | 2-ch RS232, reserved for communication with peripherals |
| Alarm Input | 2-ch sensor input |
| Positioning Module | Built-in GPS / BDS Positioning Module |
| 4G | Built-in 4G module, TDD-LTE, FDD-LTE |
| WIFI | Built-in, 2.4G, 802.11b/g/n, STA or AP mode |
| TF Card | Supports 1 TF card, 16G/32G/64G/128G/256GB/512GB |
| USB | Micro USB interface |
| Upgrade | TF card and OTA |
| AI – ADAS | Lane departure, collision alarm, distance detection, pedestrian detection, etc. |
| AI – DSM | Fatigue driving detection, smoking, mobile phone use, occlusion, unsafe driving behavior detection |
| AI – BSD | Blind spot detection |
| Input Voltage | DC: +10V ～ +36V |
| Power Consumption | Normal working state < 5W (without external equipment) |
| Power Off Protection | Super capacitor design, supports abnormal power failure, ensures the integrity of video files |
| Working Temperature | -25℃ to +70℃ |
| Working Relative Humidity | 20% to 80% |
| Equipment Size | 138mm x 85mm |
